High Speed Precision Lathe

High Speed Precision Lathe - YT-1430ST

YT-1430ST

12 STEPS SPINDLE SPEED

  • Bed Way Hardended & Ground
  • Headstock with Oil Bath Lub. System
  • Foot Brake Pedal
  • Headstock Gears with Precision Hardened and Ground

Spec YT-1430ST

UNIT : mm / 60Hz

MODEL
YT-1430ST
Swing Over Bed mm
355
Swing Over Cross Slide mm
225
Swing Over Gap mm
510
Length of Gap mm
200
Bed Width mm
230
Between Center Distance mm
750
Spindle Bore mm
52
Spindle Nose mm
D1 - 5 Camlock
Taper of Spindle Bore
MT-6
Spindle Speeds rpm
80 - 2000
Spindle Step
12 Steps
Spindle Center to Ground mm
1066
Longitudinal Feeds
12 Kinds. 0.068 - 0.936 mm/rev, 16 Kinds. 0.0026 - 0.0638”/ rev
Cross Feeds
12 kinds. 0.034-0.468 mm/rev, 16 kinds. 0.0013 - 0.0319”/ rev
Inch Threads Range
( 30 Numbers ) 0.4 - 7.0 mm = PITCH
Metric Threads Range
( 32 Numbers ) 4 - 56 TPI
Cross Slide Travel mm
177
Top Slide Travel mm
100
Tool Shank mm
20 x 20
Tailstock Quill Diameter mm
40
Tailstock Quill Travel mm
100
Taper of Tailstock Quill
MT-3
Spindle Motor
3 HP / 5 HP ( Opt. )
Machine Dimensions mm
65 x 153 x 117
Machine Net Weight kgs
550

* The above machine specification is subject to change without previous notice due to the continuous improvement of R&D.

STANDARD ACCESSORIES

1. Back Plate
2. Center Sleeve
3. Centers
4. Rear Splash Guard
5. Operate Manual & Parts List
6. Tool Box & Kits
7. Leveling Pad

OPTIONAL ACCESSORIES

1. Steady Rest
2. Follow Rest
3. Face Plate
4. 3 Jaw Scroll Chuck
5. 4 Jaw Independent Chuck
6. Quick Change Toolpost
7. Micro Bed Stop
8. 4 Position Carriage Stop
9. Work Light
10. DRO
11. Drill Chuck
12. Live Center
13. Taper Turning Attachment
14. 5C Collet Closer
15. Chuck Guard
16. 1/8 HP Coolant Pump
17. Tool Post Guard
